Комутатор Cisco Catalyst 2960-X 24 GigE

★★★★★ (0 ревюта)

CISCO

_модел WS-C2960X-24TS-L

_цена 5745.6 лв.

_{код на продукта} 9055

_{наличност} при доставчик

Добави в количката

Описание на продукта

Cisco Catalyst 2960-X 24 GigE, 4 x 1G SFP, LAN Base Виж характеристиките

Характеристики

Суич, тип

Fixed Port
Общ брой портове

28
Основни портове, тип

24x10/100/1000Base-T
Power Over Ethernet (PoE)

No
Uplink портове

4xSFP
Свободни (10GB) слотове

No
Управление

CLI for detailed configuration and administration, DHCP, Internet Group Management Protocol (IGMP), Trivial File Transfer Protocol (TFTP), SNMP v1, v2c, and v3, RMON, TCP, UDP
Stackable

FlexStack Plus for stacking of up to 8 switches with 80 Gbps of stack throughput (optional)
Fans

Fanless design
Захранване

One fixed power-supply and options for an external redundant power supply source (RPS2300). The internal power supply is an auto-ranging unit and supports input voltages between 100 and 240V AC.
Routing

Layer 2 Only
Памет (Flash, RAM)

Flash memory: 128 MB; RAM: 512 MB DRAM
Капацитет за маршрутизиране/превключване, Gbps

216 Gbps
Пропускателна способност, Mpps

71.4 Mpps
MAC адреси

-
VLAN (брой, стандарти)

Maximum active VLANs: 1023; IEEE 802.1Q VLAN
QoS

Up to eight egress queues per port (four on the 2960-X or when stacking the 2960-XR) and strict priority queuing so that the highest priority packets are serviced ahead of all other traffic; SRR; WTD; 802.1p class of service; DSCP; Rate limiting
L2 мрежови стандарти

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3az, IEEE 802.1ae, IEEE 802.3ae, IEEE 802.1ax, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3x, IEEE 802.1ab, IEEE 802.3ad, IEEE 802.3ah
L3 мрежови стандарти

-
IPv6 functionality

IPv6 Ready Logo, IPv6 Aggregatable Addrs, IPv6 Neighbor Discovery, IPv6 Autoconfiguration, ICMP IPv6
Сигурност

Cisco TrustSec, 802.1X, Cisco Threat Defense, Private VLANs, RPF, ACLs, SSH, SPAN, TACACS+ and RADIUS authentication, MAC Address Notification, Multilevel security on console access, BPDU guard, STRG, IGMP filtering, Dynamic VLAN assignment
Размери (Ш, Д, В), mm

445 x 279 x 45
Опция за монтаж

Rackmount
Други

System Software: LAN Base
