Комутатор Cisco Catalyst 2960 Plus 24 10/100 + 2 T/SFP LAN Lite

★★★★★ (0 ревюта)

CISCO

_модел WS-C2960+24TC-S

_цена 1729.29 лв.

_{код на продукта} 9068

_{наличност} при доставчик

Добави в количката

Описание на продукта

Cisco Catalyst 2960 Plus 24 10/100 + 2 T/SFP LAN Lite Виж характеристиките

Характеристики

Суич, тип

Fixed Port
Общ брой портове

26
Основни портове, тип

24x10/100Base-TX
Power Over Ethernet (PoE)

No
Uplink портове

2 dual personality
Свободни (10GB) слотове

No
Управление

CLI for detailed configuration and administration, DHCP, Internet Group Management Protocol (IGMP), Trivial File Transfer Protocol (TFTP), SNMP v1, v2c, and v3, RMON, TCP, UDP
Stackable

No
Fans

Fanless design
Захранване

Internal power supply is an auto-ranging unit and supports input voltages between 100 and 240V AC. The Cisco RPS connector offers connection for an optional Cisco RPS 2300 (model PWR-RPS2300) that uses AC input and supplies DC output to the switch.
Routing

Layer 2 Only
Памет (Flash, RAM)

Flash memory: 64 MB; RAM: 128 MB DRAM
Капацитет за маршрутизиране/превключване, Gbps

16 Gbps
Пропускателна способност, Mpps

6.5 Mpps
MAC адреси

-
VLAN (брой, стандарти)

Maximum active VLANs: 64; IEEE 802.1Q VLAN
QoS

Four egress queues per port and strict priority queuing so that the highest priority packets are serviced ahead of all other traffic; Shaped Round Robin (SRR) scheduling and Weighted Tail Drop (WTD) congestion avoidance; 802.1p class of service; DSCP
L2 мрежови стандарти

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1X, IEEE 802.1ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3x
L3 мрежови стандарти

-
IPv6 functionality

IPv6 Neighbor Discovery, IPv6 Autoconfiguration, ICMP IPv6
Сигурност

Flexible Authentication, 802.1x Monitor Mode, and RADIUS Change of Authorization; Threat defense features including Port Security, Dynamic ARP Inspection, and IP Source Guard; Private VLAN Edge to provide isolation between switch ports
Размери (Ш, Д, В), mm

450 x 242 x 44
Опция за монтаж

Rackmount
Други

System Software: LAN Lite
