Комутатор Cisco CBS350 Managed 24-port SFP+

★★★★★ (0 ревюта)

CISCO

_модел CBS350-24XS-EU

_цена 4756.85 лв.

_{код на продукта} 19748

_{наличност} при доставчик

Добави в количката

Описание на продукта

Cisco CBS350 Managed 24-port SFP+, 4x10GE Shared Виж характеристиките

Характеристики

Суич, тип

Fixed Port, Managed
Общ брой портове

25
Основни портове, тип

20x 10G SFP+
Power Over Ethernet (PoE)

-
Uplink портове

4x 10G copper/SFP+ combo
Свободни (10GB) слотове

-
Управление

1x GE OOB management; Web based; Cisco Business Dashboard; on-device UI, CLI, and SNMP
Stackable

Up to 4 units in a stack. Up to 192 ports managed as a single system with hardware failover
Fans

4
Захранване

Internal (100-240V, 50-60 Hz)
Routing

Dynamic Layer 3 routing
Памет (Flash, RAM)

Flash: 256 MB; CPU memory: 512 MB, Packet buffer: 3 MB
Капацитет за маршрутизиране/превключване, Gbps

480 Gbps
Пропускателна способност, Mpps

240 Mpps
MAC адреси

16K
VLAN (брой, стандарти)

Support for up to 4094 VLANs simultaneously; Port-based and 802.1Q tag-based VLANs; MAC/protocol-based VLAN; IP subnet-based/Management VLAN; Private VLAN; PVE; Guest/unauthenticated VLAN; Dynamic VLAN assignment via RADIUS server; Voice/Multicast TV VLAN
QoS

Priority levels: 8 hardware queues; Scheduling: Strict priority and Weighted Round-Robin (WRR); Class of service: Port based; 802.1p VLAN priority-based; IPv4/v6 IP precedence/Type of Service (ToS)/DSCP-based; DiffServ; ACLs, trusted QoS
L2 мрежови стандарти

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3z, IEEE 802.3x Flow Control, IEEE 802.3 ad LACP, IEEE 802.1D (STP), IEEE 802.1Q/p VLAN, IEEE 802.1w RSTP, IEEE 802.1s Multiple STP, IEEE 802.1X, IEEE 802.3af, IEEE 802.3at, RFC
L3 мрежови стандарти

BOOTP/DHCP
IPv6 functionality

IPv6 host mode; IPv6 over Ethernet; Dual IPv6/IPv4 stack; IPv6 neighbor and router discovery (ND); IPv6 stateless address autoconfiguration; MTU discovery; DAD; ICMP v6; DHCPv6 stateful client; ISATAP
Сигурност

SSL; IEEE 802.1X port security; ARP; IP Source Guard; DHCP; IPMB; IPv6 First Hop Security; SCT; DoS
Размери (Ш, Д, В), mm

440 x 350 x 44 mm
Опция за монтаж

Rackmount
Други

Cisco standard RJ45 console port; USB Type-A slot on the front panel of the switch for easy file and image management
